- Fast & Powerful: A 4-stroke engine with a maximum output of 5.1kW and 7hp, and a maximum speed of 6000rpm, provides you with unparalleled speed. The streamlined design of a 6.3'' three-blade propeller can reduce water resistance and provide stronger power during operation.
- Selected Material: Lightweight and sturdy aluminum alloy, combined with spray painting technology, provides excellent corrosion resistance, wear resistance, heat resistance, shock resistance, deformation resistance, and other properties. You can use it with confidence in fresh water and salt water.
- Easy to Operate: The throttle lever directly controls acceleration and steering. The step-less speed regulation allows you to easily adjust the running speed, combined with simple gear shifting (forward, neutral, or reverse), bringing you a more comfortable and convenient user experience.
- Safe & Reassuring: The reliable TCI ignition system can quickly and safely start the motor, and suspension tilt adjustment pins and anti-vortex plates reduce inclination and vortices, ensuring smooth operation. The efficient heat dissipation holes coupled with overheating protection, allow you to continuously enjoy the fun of the navigation.
- Wide Application: This outboard motor is suitable for rubber boats, inflatable boats, fishing boats, sailboats, yachts, canoes, kayaks, rubber boats, aluminum alloy boats, etc. with a stern height of 19.88 inches or less, assisting aquaculture, water transportation, net fishing, luring, outboard backup, outings, and river cleaning/maintenance.
Specifications
Material: Aluminum Alloy, Rubber
Color: Black
Surface Treatment: Spray Paint
Assembly Required: No
Number of Items: 1
Engine: 4-stroke 7hp
Displacement: 196cc
Gear Ratio: 2.08(27:13)
Number of Cylinders: 1
Max. Output: 5.1KW
Max. Speed: 4500-6000r/Min
Gear Positions: F-N-R
Ignition System: TCI
Cooling System: Air-cooling
Control System: Tiller Control
Starting System: Manual Start
Fuel: No.92 Lead-free Gasoline or Above
Engine Oil Type: 4-stroke Engine Oil
Trim And Tilt System: Manual Tilt
Fuel Tank Capacity: 1.4L/0.37gal
Fuel Consumption Rate: About 1.5L/0.39gal/h
Propeller Diameter: 16cm/6.3in
Joystick Length: 42cm/16.53in
Handle Length: 13cm/5.12in
Fixed Screw Spacing: 15cm/5.9in
Adaptive Transom Plate Height: ≤50.5cm/19.88in
Gross Weight: 30kg/66lbs
Net Weight: 25.95kg/57.2lbs
Product Size: 53*35*117cm/20.86*13.78*46in
Package Size: 123*43*60cm/48.42*16.9*23.62in
Package Included
1x Outboard Motor
1x Tool Kit
1x Funnel
1x English Manual
Notes
1. Please carefully read the manual and strictly follow the precautions to have a better experience.
2. Please measure the height of your boat before purchasing to ensure suitability for this product.
3. Please start the motor in the water.
4. Please note that this product should use 92 # unleaded gasoline or above, and an appropriate amount of 4-stroke engine oil needs to be added through a dedicated oil filling hole for lubrication.
5. Please do not drive too fast during the running-in period. After the running-in period, the gear oil needs to be replaced, and the second replacement time is about 100 hours or 6 months later.
6. After cruising in seawater or turbid water, please clean the outboard motor with fresh water. The engine should be stored in a dry and well-ventilated place, and avoid direct exposure to sunlight.
7. If not in use for a long time, please thoroughly clean the gasoline in the fuel tank.
8. Please allow the slight color difference caused by the shooting light and 1-3cm error due to manual measurement, and make sure you do not mind before you order.
